Factory-blended 0.5–1.5 mm quartz gives consistent anti-slip texture
Pedestrian walkways and ramps
Rayson GripSafe AP12
Rayson GripSafe AP12 is a one-pack, self-crosslinking acrylic primer filler loaded with 0.5–1.5 mm silicate quartz aggregate that builds an anti-slip texture directly onto concrete and asphalt.
Best for
Best for putting reliable anti-slip texture on walkways, ramps, playgrounds and courts in a single ready-to-use product.
Real product · Interactive depth view Rayson GripSafe
Product system Rayson GripSafe AP12
22 L plastic pail RY-TDS-801
Rayson GripSafe AP12 has one clearly defined, verifiable job in the coating system.
Rayson GripSafe AP12 is a one-pack, self-crosslinking acrylic primer filler loaded with 0.5–1.5 mm silicate quartz aggregate that builds an anti-slip texture directly onto concrete and asphalt. Best for putting reliable anti-slip texture on walkways, ramps, playgrounds and courts in a single ready-to-use product.
One pack, ready to use — no broadcasting step
Industrial floors requiring slip resistance
Fast-drying with high abrasion and excellent water resistance
Playgrounds, basketball courts and tennis courts
Consistent grip in one ready-to-use coat.
A quartz-filled acrylic primer that builds reliable anti-slip texture on concrete and asphalt without a separate broadcast step.
A controlled route to applying Rayson GripSafe AP12.
This sequence supports early planning. It does not replace the current Technical Data Sheet, approved method statement or project-specific technical review.
- 01
Inspect and prepare the substrate
Grey concrete
- 02
Prepare the material as specified
Single component, ready to use; condition material to 15–25 °C before use
- 03
Apply with the correct tools
Recommended methods: Trowel or squeegee, Brush for stripe-coating edges. Confirm coat count and thickness for the project.
- 04
Protect through the required cure
Touch dry 30–60 minutes at 25 °C; recoat after 2–4 hours; full cure 1 day
Coating system cutaway
Every layer has a job—from prepared substrate to service surface.
This diagram explains a typical system position, not a fixed specification. Primer, body coat, finish, thickness and detailing must be confirmed for the project.
Position in the system Primer
Rayson GripSafe AP12 serves as the primer. Confirm the complete build-up against the substrate, exposure and project requirements.
Related system products
Review primers, body layers, finishes or specialist components connected to this product.
- Rayson GripSafe AP12Primer · Acrylic
- Compatible system baseSelected for the required specialist performance
- Correctly prepared substrateGrey concrete
Four project facts for faster system screening.
These current product figures support early selection. Confirm the final build-up, quantity and application conditions against the Technical Data Sheet and site conditions.
- Coverage
- Coverage
- Mixing & working time
- Mixing
- Drying & curing
- Curing
- Pack configuration
- Pack
Theoretical 5–8 m² per litre, subject to substrate porosity and application conditions
Single component, ready to use; condition material to 15–25 °C before use
Touch dry 30–60 minutes at 25 °C; recoat after 2–4 hours; full cure 1 day
22 L plastic pail
Confirm the substrate and real service environment before specifying.
Choose it when
- Pedestrian walkways and ramps
- Industrial floors requiring slip resistance
- Playgrounds, basketball courts and tennis courts
- Cycling pathways
Relevant applications
Relevant industries
Choose something else when
- Ambient and surface temperature above 10 °C, and at least 5 °C above the dew point
- Surface must be dry, clean and free of loose paint, dust, grease, oil, wax and biological growth
- Neutral colour only — pair with a coloured finish coat where colour is required
- Texture grade is fixed by the factory aggregate blend
- Smooth decorative finishes — the aggregate texture is the point
- Glazed tiles or non-porous glossy surfaces without specialist preparation
- Heavy forklift traffic areas — use an epoxy or PU-cement system
- Application below 10 °C or onto damp, contaminated surfaces
Other Rayson products to evaluate
These links continue the comparison; they are not automatic substitutes. Confirm the substrate, exposure and complete build-up before selection.
Substrate requirements+
- Grey concrete
- Asphalt surfaces
- Hard surfaces such as stone
- Unglazed tiles and pavers
Technical documents and project support
Ready to specify Rayson GripSafe AP12? Give Rayson the site conditions.
Send the area, substrate condition, expected traffic or exposure, required finish and programme. The technical team can help review the system build-up and estimated quantity.
What to know before specifying Rayson GripSafe AP12.
How does GripSafe AP12 differ from broadcasting aggregate?
The quartz is pre-blended into the product, so texture is uniform with no broadcasting, sweeping or wastage — and no thin spots where the grit missed.
Does it need a topcoat?
It works as a stand-alone anti-slip coat in its neutral colour; where colour or extra cleanability is wanted, overcoat with UraForce HY15 or CourtFlex AC25.
How aggressive is the texture?
The aggregate is graded 0.5–1.5 mm — a firm pedestrian anti-slip profile. If you need a specific measured slip rating for compliance, confirm the requirement with our technical team.
Can it go on asphalt?
Yes — asphalt is a listed substrate alongside concrete, stone, unglazed tiles and pavers.
How soon can it be recoated or walked on?
Indicatively touch dry in 30–60 minutes, recoatable in 2–4 hours and fully cured in a day at 25 °C.
